Toolbar

The Carousel Toolbar plugin is used under the hood to create a toolbar element with configurable items - buttons, links, or any HTML content. Here are examples of how to customize it for Fancybox.

Transformation controls

Use any transformation button provided by the Panzoom component:

Fancybox.bind("[data-fancybox]", {
  Carousel: {
    Toolbar: {
      display: {
        left: ["counter"],
        middle: [
          "zoomIn",
          "zoomOut",
          "toggle1to1",
          "rotateCCW",
          "rotateCW",
          "flipX",
          "flipY",
          "reset",
        ],
        right: ["autoplay", "thumbs", "close"],
      },
    },
  },
});

JS Bin Example

Download button

A download button is also available. Use the data-download-src attribute to customize the download link for the download button. Optionally, use the data-download-filename attribute to suggest a filename.

<a
  href="https://lipsum.app/id/15/1600x1200/"
  data-fancybox="gallery"
  data-download-src="https://lipsum.app/id/15/3200x2400"
>
  <img src="https://lipsum.app/id/15/200x150" />
</a>

Fancybox.bind("[data-fancybox]", {
  Carousel: {
    Toolbar: {
      display: {
        left: ["counter"],
        middle: [],
        right: ["download", "thumbs", "close"],
      },
    },
  },
});

JS Bin Example

Custom button

Use the items option to populate the available toolbar items. Each object should have a tpl property containing the item template and optional click property containing the method that will be executed when clicked.

Fancybox.bind("[data-fancybox]", {
  Carousel: {
    Toolbar: {
      items: {
        facebook: {
          tpl: '<button class="f-button"><svg><path d="M18 2h-3a5 5 0 0 0-5 5v3H7v4h3v8h4v-8h3l1-4h-4V7a1 1 0 0 1 1-1h3z"/></svg></button>',
          click: () => {
            window.open(
              "https://www.facebook.com/sharer/sharer.php?u=" +
                encodeURIComponent(window.location.href) +
                "&t=" +
                encodeURIComponent(document.title),
              "",
              "left=0,top=0,width=600,height=300,menubar=no,toolbar=no,resizable=yes,scrollbars=yes"
            );
          },
        },
        twitter: {
          tpl: '<button class="f-button"><svg><path stroke="none" d="M0 0h24v24H0z"/><path d="M22 4.01c-1 .49-1.98.689-3 .99-1.121-1.265-2.783-1.335-4.38-.737S11.977 6.323 12 8v1c-3.245.083-6.135-1.395-8-4 0 0-4.182 7.433 4 11-1.872 1.247-3.739 2.088-6 2 3.308 1.803 6.913 2.423 10.034 1.517 3.58-1.04 6.522-3.723 7.651-7.742a13.84 13.84 0 0 0 .497-3.753c0-.249 1.51-2.772 1.818-4.013z"/></svg></button>',
          click: () => {
            window.open(
              "http://twitter.com/share?url=" +
                encodeURIComponent(window.location.href) +
                "&text=" +
                encodeURIComponent(document.title),
              "",
              "left=0,top=0,width=600,height=300,menubar=no,toolbar=no,resizable=yes,scrollbars=yes"
            );
          },
        },
      },
      display: {
        left: ["infobar"],
        middle: [],
        right: ["twitter", "facebook", "close"],
      },
    },
  },
});

Dynamic

Since Fancybox displays an instance of the Carousel, you can use its breakpoints option to display toolbar items depending on the screen size, example:

Fancybox.bind("[data-fancybox]", {
  Carousel: {
    Toolbar: {
      display: {
        left: ["counter"],
        middle: [],
        right: ["thumbs", "close"],
      },
    },
    breakpoints: {
      "(min-width: 768px)": {
        Toolbar: {
          display: {
            left: ["counter"],
            middle: [
              "zoomIn",
              "zoomOut",
              "toggle1to1",
              "rotateCCW",
              "rotateCW",
              "flipX",
              "flipY",
            ],
            right: ["autoplay", "thumbs", "close"],
          },
        },
      },
    },
  },
});

JS Bin Example
